Waterproof housing Ikelite for PANASONIC GH5, GH5S et GH5II

DL200 Waterproof Housing (DRY LOCK) for Panasonic Lumix GH5, GH5S, GH5-II

The new-generation DL200 housing offers an optimized grip and ergonomic access to controls. Its transparent Lexan back door makes it easy to check the proper positioning of the camera. The specially formulated gray tint reflects sunlight, reducing overheating, especially when shooting in 4K. Unlike black or clear models, this color improves LCD screen readability.

The levers and buttons provide access to most controls. A TTL converter (sold separately) compatible with the GH5-II, GH5S, and GH5 ensures automatic calculation of the external flash power. The flash socket with a waterproof connection allows the use of Ikelite strobes (DS51, 125, 160, 161, 162, 230). Wired synchronization disables the internal flash, extending battery life.

The housing features an extra-large zoom control for precise focal length adjustment and a 1/2" vacuum valve for a pre-dive waterproof test (pump sold separately). Ideal for diving, water sports (surfing, pool, etc.), and underwater photography. An M16 port is integrated, with the option to add an M24 port for an external HDMI monitor (optional, contact us for details).

Box contents:

• DL200 housing
• Pre-installed O-rings: rear (IKE 0132-61), front (IKE 0132-45)
• Zoom gear retainer (IKE 75900) (installed)
• Port cover (IKE 0200-92) (installed)
• Waterproof cap (IKE 9104-7) (installed)
• Base with left quick-release handle (IKE 4077-67) (installed)
• Zoom gear retainer tool (IKE 0945-06)
• 0.050" hex key (IKE 0945-11)
• Silicone lubricant tube (1 cc)

Warning: The port is not included. It is essential for waterproofing and must be chosen according to the lens. Contact us for personalized advice.

Accessible controls:

Access to all essential controls except:

• Viewfinder diopter adjustment
• Rear dial
• Rear dial lock button (must be unlocked before inserting the camera)

Compatible ports and domes:

Compatible with most lenses thanks to the DL "DRY LOCK" system.

Compatible accessories:

A range of accessories and spare parts is available in the Accessories tab.

Need advice? Contact us to verify compatibility with your equipment.

Compatible external strobes:

An external strobe enhances color rendering and exposure. Fiber optic synchronization is not possible.

For TTL with Ikelite strobes, a Panasonic PT1 TTL converter (IKE 46032) is required (sold separately).

Recommended strobes:

• DS51 II (TTL with PT1 converter (IKE 46032) and manual)
• DS160 II (TTL with PT1 converter (IKE 46032) and manual)
• DS230 (TTL with PT1 converter (IKE 46032) and manual)
• Sea & Sea YS-D3 Duo (manual mode only)

Compatible lighting:

Photo and video lighting solutions are available. Contact us for tailored recommendations.
